Model 111-ED Heavy Duty End Dump Truck Unloader

Rock Systems Heavy Duty End Dump Truck Unloader, Model 111-ED complete as follows:

a) 52" wide x 20' long vibrating grizzly feeder complete with 14' solid pan impact section and 6' long adjustable grizzly bar section; bolted vibrator assembly with timed eccentric shafts; self-aligning spherical roller bearings; oil bath lubrication; bolt-on abrasion resistant liners; 40 h.p. electric motor; pivoted motor base; drive and driven sheaves; v-belts; OSHA drive guard; heavy duty spring supports and springs.

b) 50 ton capacity rock box receiving hopper constructed of 3/4" thick plate steel with reinforcing.

c) Collecting hopper located under grizzly section to contain product passing through the grizzly section.

d) Heavy duty support structure constructed of wide flange beams with reinforcing.

e) Heavy duty skid frame constructed of wide flange beams with reinforcing.

f) One rust inhibitor prime coat and one finish coat gray paint for all equipment; one finish coat safety yellow paint for all guarding.
